About This Project


  • A patented coupling type clamping system along with 8 hydraulic locking pins keep the tool in place during heavy stock removal.
  • When in use, the turning tool holder a 0.5mm space between spindle taper and tool taper, eliminating load stress on ram spindle bearings and substantially prolonging spindle life.
  • High rigidity NN bearings, 20HP high torque spindle motor and 2500rpm spindle speed combine to deliver heavy duty performance for milling, drilling, tapping and grinding applications.(ZF gearbox is offered as an option.)
  • Programmable ±100mm Y axis design is ideally suited for slot milling and multi-task machining applications.
  • The rotary table is driven by powerful spindle motor with ZF gearbox, for low speed machining with high torque or high speed machining for fine finishing.



  • Siemens 840D controller.
  • Automatic grinding function.
  • ZF gearbox for milling spindle.
  • Linear scales for X,Z axis.
  • Automatic tool length measurement.
  • Workpiece measurement.
  • 70,50,or 20 bar coolant through spindle(CTS).
  • Cartridge type filter system for CTS.
  • Paper type filter system for CTS.
  • Centrifuge type filter system for CTS.
  • Chiller for coolant system.
  • 3-jaw hydraulic chuck.
  • 4-jaw independent chuck.
  • 32T tools magazine.
  • 48T tools magazine.
  • Workpiece cleaning gun(air).
  • Workpiece cleaning gun(water).
  • Operator platform.
  • Turning tool holders for VTC+CY:
    OD toolholder / ID boring bar / OD boring bar.
  • Rotary tool holders for VTC+CY:
    Collet chuck holder (tapping)
    Collet chuck holder (drilling)
    Weldon chuck holder (with two coolant channels)
    Modular boring head
    Face milling holder.
  • Grinding tools.

Other dimensions on request


Download the catalogue

Contact us to commerciale@comispa.it to receive more information



Box Way Structure

Spindel Motor: up to 100HP

Max. Swing Dia.: up to 2,500mm (98")

Table Dia.: up to 2,000mm (78")

Max. Weight: up to 13,600kg (30,000 lbs.)

Transmission: 2-Speed Gearbox

Live Tooling, C-Axis and Y-Axis Available

Grinding Attachment Available

Milling and grinding function available
